RAKON超稳定TCXO温补型晶振

产品优势：

RAKON高精度温补晶振，工作温度-40to85°；专业高频50MHZ,100MHZ,200MHZ,500MHZ

联系我们18926758761

立即购买

Ultra Stable TCXO
APPLICATIONS: Precision Positioning, Test and Measurement, Telecommunications, High Reliability Defense, Stratum 3, IEEE 1588, SyncE, SONET, SDH, WDM, OTN, Carrier Networking, Carrier Ethernet, Microwave, Backhaul, Transport Equipment, Small Cells (WCDMA, LTE, LTE-A), Enterprise Networking.
Model	Image	Package	Frequency Range	Stability	Output	Features
				(FvsT)
RPT7050A		7.0 x 5.0 mm	1.25 – 52 MHz	±0.05 – 2.5 ppm	Clipped sinewave	6 pin, 2.5 – 5.7 V
New				(-55°C to 105°C)	Sinewave	Positioning
					HCMOS	Test and Measurement
					ACMOS	Hi-rel / Defense
RPT5032A		5.0 x 3.2 mm	1.25 – 52 MHz	±0.05 – 2.5 ppm	Clipped sinewave	6 or 10 pin, 2.5 – 5.7 V
New				(-55°C to 105°C)	Sinewave	Positioning
					HCMOS	Test and Measurement
					ACMOS	Hi-rel / Defense
RPT7050J		7.0 x 5.0 mm	10 – 40 MHz	±0.1 – 0.28 ppm	HCMOS	6 pin, 3.3 V
New				(Holdover stability,		Networking
				-40°C to 85°C)
RPT5032J		5.0 x 3.2 mm	10 – 40 MHz	±0.1 – 0.28 ppm	HCMOS	6 pin, 3.3 V
New				(Holdover stability,		Networking
				-40°C to 85°C)
RPT7050P		7.0 x 5.0 mm	19.2 – 40 MHz	±0.05 – 0.25 ppm	Clipped sinewave	6 pin, 2.5 – 5.7 V
New				(-40°C to 85°C)	HCMOS	Small Cells
RPT5032P		5.0 x 3.2 mm	19.2 – 40 MHz	±0.05 – 0.25 ppm	Clipped sinewave	6 pin, 2.5 – 5.7 V
New				(-40°C to 85°C)	HCMOS	Small Cells
RPT7050N		7.0 x 5.0 mm	12.8 – 26 MHz	±0.05 – 0.1 ppm	Clipped sinewave	6 pin, 2.5 – 5.7 V
New				(-40°C to 85°C)	HCMOS	Small Cells
RPT5032N		5.0 x 3.2 mm	12.8 – 26 MHz	±0.05 – 0.1 ppm	Clipped sinewave	4 or 6 pin, 2.5 – 5.7 V
New				(-40°C to 85°C)	HCMOS	Small Cells
RFPT400		5.0 x 3.2 mm	10 - 30 MHz	±0.08 - 0.25 ppm	Clipped sinewave	Femtocell
.				(0 to 70°C)
RFPT500		7.0 x 5.0 mm	10 - 30 MHz	±0.14 - 0.28 ppm	HCMOS	Stratum 3
.				(-40 to 85°C)
CFPT9300		5.0 x 3.2 mm	1.25 - 52 MHz	±0.2 - 2.0 ppm	HCMOS	Communications
.				(-40 to 85 °C)	Clipped sinewave
CFPT9000		7.0 x 5.0 mm	10 - 40 MHz	±0.2 - 2.5 ppm	Sinewave	Communications
.				(-40 to 85°C)	Clipped sinewave	Acceleration sensitivity
					HCMOS
CFPT9050		14.7 x 9.2 mm	1 - 80 MHz	±0.3 - 2.5 ppm	Sinewave	High frequency TCXO
.				(-55 to 105°C)	Clipped sinewave	Communications
					HCMOS
Application Note	Application notes for 7050 series USTCXO Network Timing
.

Rakon温补晶振超稳定的TCXO产品提供了最高的频率稳定度的TCXO的表现，但没有成本高，功耗。
超稳定的Rakon温补晶振解决大批量应用在很高的稳定性是必需的，以消除调整TCXO的控制电压的不利影响，以便长期漂移。紧随着的稳定性为100ppb（1 × 10-7）温度和输出多种选择，这些产品非常适合家庭无线基站，求救信标和其它高容量，稳定性要求苛刻的应用。

产品特征：

产品各项指标支持定制，精度/相噪/电压/封装均可按客户要求定制！

主要卖点：

符合国军标各项标准，产品性能稳定；

封装小，功率小，精度高，频率高；

低相噪-155 dBc/Hz

规格参数：

频率：10.000000MHz(10MHZ,12.8MHZ,19.2MHZ,20MHZ,40MHZ,100MHZ)

电压：3.3V

精度：0.1PPm

波形：正弦波,方波

相噪：-145bBc/-1KHz
